Blackmagic Design Mini Converter - UpDownCross HD Conversie 3G/HD/SD-SDI Up/Down/Cross 1 x Input 3G/HD/SD-SDI 2 x Output 3G/HD/SD-SDI & 1 x Loopout 1 x Input HDMI & 1 x Output HDMI Technical specifications connections SDI video inputs 1 connection for SD, HD or 3G-SDI video and 1 external reference input HDMI video inputs HDMI type A input SDI video outputs 2 SDI outputs; 1 SDI output with loop through HDMI video outputs HDMI output type A; Output supports the EDID data of the monitor SDI rates 270 Mbit; 1.5G; 3G Reference inputs Black Burst and Tri-Sync for SD and HD Multi-rate support Automatic detection of incoming SDI signals in HD or standard definition Updates and configuration USB Reclocking Yes Norms SD video standards 525i / 59.94 NTSC; 625i / 50 PAL HD video standards 720p / 50; 720p / 59.94; 720p / 60 1080p / 23.98; 1080p / 24; 1080p / 25; 1080p / 29.97; 1080p / 30; 1080p / 50; 1080p / 59.94; 1080p / 60 1080PsF / 23.98; 1080PsF / 24 1080i / 50; 1080i / 59.94; 1080i / 60 Video standards for HDMI input 525i / 59.94; 625i / 50; 720p / 50; 720p / 59.94; 720p / 60 1080p / 23.98; 1080p / 24; 1080p / 25; 1080p / 29.97; 1080p / 30; 1080p / 50; 1080p / 59.94; 1080p / 60 1080i / 50; 1080i / 59.94; 1080i / 60 SDI compliance SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M Level A or Level B, ITU-R BT.601, ITU-R BT.656 SDI video rates SDI video connections can be switched between standard definition and high definition SDI video sampling frequency 4: 2: 2 SDI audio sampling frequency Standard television sample rate of 48 kHz and 24 bit SDI color accuracy 4: 2: 2 SDI color space YUV Automatic SDI switching Automatic detection of SD, HD and 3G-SDI Format conversion Video conversion Converts any SD and HD input to 525i / 59.94; 625i / 50; 720p / 50; 720p / 59.94; 720p / 60 1080p / 23.98; 1080p / 24; 1080p / 25; 1080p / 29.97; 1080p / 30; 1080p / 50; 1080p / 59.94; 1080p / 60 1080i / 50; 1080i / 59.94; 1080i / 60 Computer scaling Scales the DVI resolutions 640x480, 800x600, 1024x768 to 525i / 59.94; 625i / 50; 720p / 50; 720p / 59.94; 720p / 60 1080p / 23.98; 1080p / 24; 1080p / 25; 1080p / 29.97; 1080p / 30; 1080p / 50; 1080p / 59.94; 1080p / 60 1080i / 50; 1080i / 59.94; 1080i / 60 software Product software upgrade Via the supplied updater application Control of settings steering Mini switches Electricity demand Power supply 12V universal power supply with plug adapters suitable for all countries included Power consumption 5 watts Operating voltage range 6-36 V DC Physical specifications Dimensions 135 x 92 x 24 mm (LxWxH) weight 247 kg Surroundings operating temperatur 0 to 40 ° C Storage temperature -20 to 45 ° C Relative humidity 0-90% non-condensing
Pret:
Vanzator: vivomag.ro
Brand: Blackmagic Design
